DF-50/55 single layer stretch film making machine

0086-577-58910222
DESCRIPTION

USE:

This machine uses LDPE and LLDPE to produce casting stretch film, which widely used in packing area for building material, auto parts, hardware parts etc.

FEATURE:

DF-50 stretch film co-extruder with following features: low noise, stable running, especially winding part is controlled by PLC program. The machine is equipped with extruder, traction part, leveling part, edge trimming, winding and finished roll automatic changing etc.

Optional Equipment:

1)Auto load   2)Auto dry hopper  3)Motorize net changer  4)Hydraulic net changer  5)Air shaft  6)gule pump

Main Technical Parameter



Model

DF-50

DF-55

Screw Diameter

Φ50mm

φ55mm

L/D

30:1

30:1

Rational speed of screw stem

10-120rpm

10-120rpm

Finished Film Width

200-500mm

200-500mm

Finished Film Thickness

0.008-0.04mm

0.008-0.04mm

Main Motor Power

11kw

15kw

Heating power

15KW

20KW

Water Consumption

0.5m3/h

0.5m3/h

Machine Weight

3T

4T

Overall Dimensions(L*W*H)

5600*1500*1800mm

6000*1500*2500mm
